사양
인증/적합성
All NanoDrop instruments are approved to CE and UL/CSA.
호환성
DYMO 550 Turbo printer, Bluetooth keyboard, mouse and barcode reader
농도
dsDNA: Pedestal: 27,500 ng/μL BSA (IgG): Pedestal: 820 (400) mg/mL
연결
2x USB-A Ports, 1x USB-C Port, Ethernet, Bluetooth™, Wi-Fi
검출 범위
dsDNA: Pedestal: 1.0 ng/μL, Cuvette: 0.2 ng/μL, BSA (IgG): Pedestal: 0.03 (0.015) mg/mL, Cuvette: 0.006 (0.003) mg/mL
치수(길이 x 폭 x 높이)
12.6 x 7.1 x 11.0 in (32 x 18 x 28 cm)
용도(애플리케이션)
Nucleic Acid A260, A260/A280, A260/A230 and Labeled Nucleic Acids, Oligos;, Protein A280 and A205, Protein Pierce 660, Protein Bradford, Protein BCA, Protein Lowry, Labeled Proteins, OD600, UV-Vis, and Custom Methods, Acclaro Pro Applications
포함
ND Ultra Microvolume Spec
키패드
Built-in touchscreen
측정 시간
Standard: ≤7 sec Acclaro Pro: ≤30 sec
경로 길이
0.030 to 1.0 mm (auto-ranging)
광도 정확도
3% at 0.97 A, 302 nm, (Absorbance expressed at Abs/mm at 25°C)
광도 범위
10 mm equivalent: Pedestal: 0-550 A, Cuvette: 0-1.5 A
전력 소비
Operating: 15 W; Standby: 7 W
프로세서
Custom Linux
반복 가능성
Typical: 0.002 A (1.0 mm path) or 1%CV, whichever is greater (SD of 10 individual measurements at 0.97 A)
샘플 부피(미터법)
Min 1μL
시스템 요구 사항
Windows 10 or Windows 11
워런티
2 Years
파장 정확도
±1 nm
중량(영국식 단위)
Approximately 9.0 Ib.
중량(미터법)
4.1 kg
검출기 유형
2048-element CMOS Linear Image Sensor
디스플레이
10 in. High Definition Color Display
언어
Chinese, English, French, German, Japanese, Spanish, Polish, Italian, Korean
광원
Xenon Flash
제품라인
NanoDrop
스펙트럼 대역폭
1.8 nm
전압
12 VDC
Wavelength Range
190 to 850 nm
Unit Size
Each
