사양
인증/적합성
All NanoDrop instruments are approved to CE and UL/CSA.
호환성
DYMO LabelWriter 450 printer, Bluetooth keyboard, mouse and barcode reader
농도
dsDNA: Pedestal: 27,500 ng/μL
BSA (IgG): Pedestal: 820 (400) mg/mL
연결
Three USB-A ports and Ethernet enabled
검출 범위
dsDNA: Pedestal: 2.0 ng/μL, Cuvette: 0.2 ng/μL,
BSA (IgG): Pedestal: 0.06 (0.03) mg/mL, Cuvette: 0.006 (0.003) mg/mL
치수(길이 x 폭 x 높이)
20 x 25.4 x 32.3 cm (8 x 10 x 12.7 in.)
용도(애플리케이션)
Nucleic Acid A260, A260/A280, A260/A230 and Labeled Nucleic Acids;, Protein A280 and A205, Protein Pierce 660, Protein Bradford, Protein BCA, Protein Lowry, Labeled Proteins,, OD600, Kinetics, UV-Vis, and Custom Methods
포함
ND OneC Spec, Wi-Fi
키패드
Built-in touchscreen, multipoint capacitive touch
측정 시간
8 seconds
경로 길이
0.030 to 1.0 mm (auto-ranging)
광도 정확도
3% at 0.97 A, 302 nm, (Absorbance expressed at Abs/mm at 25°C)
광도 범위
10 mm equivalent: Pedestal: 0–550 A; Cuvette: 0–1.5 A
전력 소비
Operating: 12 to 18 W; Standby: 5 W
프로세서
Android™
반복 가능성
Typical: 0.002 A (1.0 mm path) or 1%CV, whichever is greater
(SD of 10 individual measurements at 0.97 A)
샘플 온도
Temperature Control (cuvette only) 37 °C
샘플 부피(미터법)
Minimum 1μL
시스템 요구 사항
Windows™ 8.1 and 10, 64 bit
파장 정확도
±1 nm
중량(영국식 단위)
7.9 lb.
중량(미터법)
3.6 kg
검출기 유형
2048-element CMOS Linear Image Sensor
디스플레이
7 in. High Definition Color Display, 1280 x 800 pixels
언어
English, French, German, Spanish, Polish, Chinese, Japanese, Korean
광원
Xenon Flash
스펙트럼 대역폭
≤1.8 nm (FWHM at Hg 254 nm)
전압
12 VDC
Wavelength Range
190 to 850 nm
Unit Size
Each
